Parameter Details
12
12.11 o: Keypad-Related Settings
YASKAWA SIEPC71061753C GA500 Technical Manual 763
■ o1-48: Trend Plot 1 Scale Maximum Value
No.
(Hex.)
Name Description
Default
(Range)
o1-48
(11C8)
RUN
Trend Plot 1 Scale
Maximum Value
Sets the maximum value for the vertical axis used to display the monitor that was set in o1-24
[Custom Monitor 1] as a trend plot. This parameter is only available with an LCD keypad.
100.0%
(-299.9 - +300.0%)
Note:
Parameter o1-47 [Trend Plot 1 Scale Minimum Value] sets the lower limit. The lower limit is (o1-47 + 0.1)%.
■ o1-49: Trend Plot 2 Scale Minimum Value
No.
(Hex.)
Name Description
Default
(Range)
o1-49
(11C9)
RUN
Trend Plot 2 Scale
Minimum Value
Sets the horizontal axis minimum value used to display the monitor set in o1-25 [Custom Monitor
2] as a trend plot. This parameter is only available with an LCD keypad.
-100.0%
(-300.0 - +299.9%)
Note:
Parameter o1-50 [Trend Plot 2 Scale Maximum Value] sets the upper limit. The upper limit is (o1-50 - 0.1)%.
■ o1-50: Trend Plot 2 Scale Maximum Value
No.
(Hex.)
Name Description
Default
(Range)
o1-50
(11CA)
RUN
Trend Plot 2 Scale
Maximum Value
Sets the maximum value for the vertical axis used to display the monitor that was set in o1-25
[Custom Monitor 2] as a trend plot. This parameter is only available with an LCD keypad.
100.0%
(-299.9 - +300.0%)
Note:
Parameter o1-49 [Trend Plot 2 Scale Minimum Value] sets the lower limit. The lower limit is (o1-49 + 0.1)%.
■ o1-51: Trend Plot Time Scale Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-51
(11CB)
RUN
Trend Plot Time Scale
Setting
Sets the time scale (horizontal axis) to display the trend plot. When you change this setting, the
drive automatically adjusts the data sampling time. This parameter is only available with an LCD
keypad.
300 s
(1 - 3600 s)
■ o1-55: Analog Gauge Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-55
(11EE)
RUN
Analog Gauge Area
Selection
Sets the range used to display the monitor set in o1-24 [Custom Monitor 1] as an analog gauge.
This parameter is only available with an LCD keypad.
1
( 0, 1 )
0 : +/- Area ( - o1-56 ~ o1-56 )
1 : + Area ( 0 ~ o1-56 )
■ o1-56: Analog Gauge Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-56
(11EF)
RUN
Analog Gauge Area Setting
Sets the value used to display the monitor set in o1-24 [Custom Monitor 1] as an analog meter.
This parameter is only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
■ o1-58: Motor Power Unit Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-58
(3125)
Motor Power Unit Selection
Sets the setting unit for parameters that set the motor rated power.
0
(0, 1)
The drive shows these parameter values in the set units:
