3.2 Operating Procedures for Utility Functions
3.2.16 Display Servomotor Model (Fn011)
3-42
2
*
Press the Key.
The Fn011 (Display Servomotor
Model) execution display will
appear. The motor and encoder
information will be displayed.
3
Press the Key.
The display will return to the Utility
Mode Main Menu.
Continued from previous page.
Step Operation Result
SGM7A
SGM7P
SGM7G
SGM7M
SGM7D
SGM7J
SGM7E
SGM7F
SGMCS-C
SGMCS-D
SGMCS-B
SGMCS-
E
SGMCS-
L
SGMCS-
M
SGMCS-
N
SGMCS-
R
SGMCV-
C
SGMCV-
D
SGMCV-
B
SGMCV-
E
SGMCV-
L
SGMCV-
M
SGMCV-
N
SGMCV-
R
A0
A1
A3
A7
AC
AD
AE
AF
32
33
34
35
36
37
38
39
72
73
74
75
76
77
78
79
Servomotor Model
No. Type
ENCORDER 01 22bit
1:BB Mtlnfo
TYPE A0 AC200V
400W
00
01
02
20
22
24
Servomotor
capacity
Servomotor
input voltage
Encoder type
No.
Type
Incremental
encoder
Multiturn
absolute encoder
Single-turn
absolute encoder
No.
Encoder Resolution
Resolution
22 bits
24 bits
20 bits
1:BB
FUNCTION
Fn010:Prm Protect
Fn011:Motor Info
Fn012:S oft Ver
Fn013 :MturnLmS et
