4.2 Operating Procedures in Parameter Copy Mode
4.2.2 Writing Parameters to the SERVOPACK (OP→SERVO)
4-6
4.2.2 Writing Parameters to the SERVOPACK
(OP→SERVO)
You can use this function to write the parameters that are saved in the
selected block in the Digital Operator to a SERVOPACK.
Operating Procedure
Step Operation Result
1
Display the Parameter Copy Mode
Main Menu, and then use the
Key or Key to select
OP→SERVO.
The currently selected function will
flash.
2
Press the Key.
The Parameter Block Selection Dis-
play will appear.
3
Use the Key or Key to
select the parameter block (00 to
06) in the Digital Operator to write
to the SERVOPACK.
4
Press the Key.
The Parameter Write Execution Dis-
play will appear.
Continued on next page.
1:S ERVO
→
OP
2:OP
→
S ERVO
3 :VERIFY
4:LIS T
1:BB COPY
00:S GD7S -R70
01:
****
02:
****
0 3 :
****
1:BB OP
→
S ERVO
00:S GD7S -R70
01:
****
02:
****
0 3 :
****
1:BB OP
→
S ERVO
00:S GD7S -R70
S tart : [WRITE]
Return: [MODE]
1:BB OP
→
S ERVO
