1.1 Digital Operator Types and Connections
1-2
1.1 Digital Operator Types and Connections
A Digital Operator is used to display and set parameters in a SERVO-
PACK.
You can use the following two types of Digital Operators with Σ-7-Series
SERVOPACKs.
• Digital Operator for Σ-V-Series and Σ-7-Series SERVOPACKs: JUSP-
OP05A-1-E
• Digital Operators for Σ-III-Series SERVOPACKs: JUSP-OP05A and
JUSP-OP05A-E
The connection methods between these Digital Operators and Σ-7-
Series SERVOPACKs are described below.
