3.2 Operating Procedures for Utility Functions
3.2.21 Display SERVOPACK and Servomotor IDs (Fn01E)
3-52
3.2.21
Display SERVOPACK and Servomotor
IDs (Fn01E)
You can use this utility function to display ID information on the SERVO-
PACK and on the Servomotor, encoder, and Option Module that are
connected to it. However, ID information for some Option Modules (e.g.,
the SGDV-OF01A) is not stored in the SERVOPACK. Not Available will
be displayed for these Option Modules.
You can use this utility function to display the following items.
* If an Option Module is not connected, Not connect will be displayed after the Module
name.
ID Information Displayed Items
SERVOPACK ID
Information
• SERVOPACK model
• SERVOPACK serial number
• SERVOPACK manufacturing date
• SERVOPACK input voltage
• Maximum applicable motor capacity [W]
• Maximum applicable rated motor current [Arms]
Motor ID Informa-
tion
• Servomotor model
• Servomotor serial number
• Servomotor manufacturing date
• Servomotor input voltage [V]
• Servomotor capacity [W]
• Rated motor current [Arms]
Encoder ID Informa-
tion
• Encoder model
• Servomotor serial number
• Encoder manufacturing date
• Encoder type/resolution
Safety Option Mod-
ule ID Information*
• Safety Option Module model
• Safety Option Module serial number
• Safety Option Module manufacturing date
• Safety Option Module ID
Feedback Option
Module ID informa-
tion*
• Feedback Option Module model
• Feedback Option Module serial number (reserved area)
• Feedback Option Module manufacturing date
• Feedback Option Module ID
To Next Page
