2.2 Monitors

2.2.3 Monitor Display Operations

2-15

Parameter/Monitor Functions

Use the Key or Key to

display Un005.

The desired items are now dis-

played.

Press the Key.

The indicator on the key will flash

and the display status will be saved.

Note: Do not turn OFF the power supply

to the SERVOPACK while the dis-

play status is being saved.

Continued from previous page.

Step Operation Result

1:BB

PRM/MON

Un000=0 00000

Un002=0 00000

Un005=

Un006=

1:BB

PRM/MON

Un000=0 00000

Un002=0 00000

Un005=

Un006=
