YASKAWA E-7 Series - Tuning-Less Level Setting (Fn200)

3.2 Operating Procedures for Utility Functions
3.2.27 Tuning-less Level Setting (Fn200)
3-67
3
Utility Functions
3.2.27 Tuning-less Level Setting (Fn200)
You can use this utility function to set the tuning-less rigidity and load
levels.
Preparations
Always check the following before you set the tuning-less rigidity and
load levels.
• The parameters must not be write-prohibited (Fn010 must be set to
0000).
• The servo must be in ready status.
• The tuning-less function must be enabled (Pn170 = n.
1).
• The test without a motor function must be disabled (Pn00C =
n.
0).
