4.2 Operating Procedures in Parameter Copy Mode
4.2.3 Verifying Parameters (VERIFY)
4-10
4.2.3
Verifying Parameters (VERIFY)
You can use this function to compare the parameters that are saved in
the selected block in the Digital Operator with the parameters in the
SERVOPACK, and display the results.
Operating Procedure
Step Operation Result
1
Display the Parameter Copy Mode
Main Menu, and then use the
Key or Key to select VERIFY.
The currently selected function will
flash.
2
Press the Key.
The Parameter Block Selection Dis-
play will appear.
3
Use the Key or Key to
select the parameter block (00 to
06) in the Digital Operator to com-
pare with the parameters in the
SERVOPACK.
4
Press the Key.
The Parameter Verify Execution Dis-
play will appear.
Continued on next page.
1:S ERVO
OP
2:OP
S ERVO
3 :VERIFY
4:LIS T
1:BB COPY
00:S GD7S -R70
01:
****
02:
****
0 3 :
****
1:BB VERIFY
00:S GD7S -R70
01:
****
02:
****
0 3 :
****
1:BB VERIFY
00:S GD7S -R70
S tart : [READ]
Return: [MODE]
1:BB VERIFY
