4.2 Operating Procedures in Parameter Copy Mode
4.2.2 Writing Parameters to the SERVOPACK (OP→SERVO)
4-9
4
Parameter Copy Functions
Additional Information on Writing Parame-
ters
• Do not disconnect the Digital Operator from the SERVOPACK while
the parameters are being written. The writing process will be can-
celed. If the Digital Operator is disconnected, some of the the param-
eters may not have been written. Repeat the operation. Turning the
power OFF and ON again before re-executing the writing operation
may cause a A.020 (Parameter Checksum Error) or A.040 (Parameter
Setting Error) alarm. To clear an alarm, initialize the parameters
(Fn005).
• If an empty block (****) is selected to write parameters, No Data will
be displayed and nothing will be written.
• If you specify writing a parameter block to a SERVOPACK with a dif-
ferent voltage or capacity, Unmatched Parameters will be displayed
and the parameters will not be written.
• If writing parameters is prohibited, Not Available will be displayed
when the servo is turned ON and the parameters will not be written.
• During the writing operation, the current process will be displayed
sequentially on the Digital Operator as shown below. The writing oper-
ation requires approximately 10 seconds.
• After the parameters have been written to the SERVOPACK, turn the
power OFF then ON again. The servo will not turn ON until the power
supply is turned OFF and ON again.
Reading Parameters from the Digital
Operator
Writing Parameters to the SERVOPACK
Operation Completed
Note: You cannot use the Key during
this display to cancel processing.
00:S GD7S -R70
Reading
Parameters ..
<< OP >>
1:BB OP
→
S ERVO
00:S GD7S -R70
Writing
Parameters ..
<< S ERVO >>
1:A.941 OP
→
S ERVO
00:S GD7S -R70
Completed
1:A.941 OP
→
S ERVO
