1.1 Digital Operator Types and Connections
1-4
Digital Operators for Σ-III-Series SERVO-
PACKs: JUSP-OP05A and JUSP-OP05A-E
You can use the Digital Operators for
Σ
-III-Series SERVOPACKs (JUSP-
OP05A and JUSP-OP05A-E) with a
Σ
-7- Series SERVOPACK. To do so,
use the JZSP-CVS05-A3-E Digital Operator Converter Cable to connect to
the SERVOPACK. Connect to the CN3 connector on the SERVOPACK.
VCMP
SVON COI N TGON REF
CHARGE
ALARM
DATA
JOG
SVON
SCROLL MODE/SET
RESET
SERVO
READ WRITE
SERVO
YASKAWA
DIGITAL OPERATOR JUSP-OP05A
SGD7 SERVOPACK
Digital Operator Converter Cable:
JZSP-CVS05-A3-E
