3.2 Operating Procedures for Utility Functions
3.2.7 Reset Absolute Encoder (Fn008)
3-22
Operating Procedure
Step Operation Result
1
Press the Key to display the
Utility Mode Main Menu, and then
use the Key or Key to
select Fn008.
2
Press the Key.
The Fn008 (Reset Absolute
Encoder) execution display will
appear.
3
Press the Key to go from from
PGCL1 to PGCL5.
4
Press the Key.
The absolute encoder will be reset.
When processing has been com-
pleted, the status display will flash
DONE for approximately one sec-
ond and then return to 1:A.810.
5
Press the Key.
The display will return to the Utility
Mode Main Menu.
6
Turn the power supply OFF and ON
again.
The parameter settings are now
enabled and the alarm will have
been cleared.
1:A.810
FUNCTION
Fn006:AlmHis t Clr
Fn008:Mturn Clr
Fn009:Ref Adj
Fn00A:Vel Adj
1:A.810
Multiturn Clear
PGCL1
1:A.810
Multiturn Clear
PGCL5
1:A.810
Multiturn Clear
PGCL5
1:A.810
FUNCTION
Fn006:AlmHis t Clr
Fn008:Mturn Clr
Fn009:Ref Adj
Fn00A:Vel Adj
