5.5 Peripheral Devices
5
Specifications and Dimensional Drawings of Cables and Peripheral Devices
5-25
(c) JUSP-RA11 Regenerative Resistor Unit
(d) JUSP-RA12 Regenerative Resistor Unit
216
45
348
M8 main circuit terminals
4 × M5 mounting holes
77
49
B1
B2
Power line insertion hole
(φ33, with rubber bushing)
Units: mm
Approx. mass: 20.5 kg
484
425
242
7.5
485
500
37
Power line insertion hole
(φ33, with rubber bushing)
M4 main circuit terminals
4 × M5 mounting holes
348
34
45
7.5
60
485
500
200
259
49
24
38
Units: mm
Approx. mass: 14 kg
B1B2
