YASKAWA HV600

Parameter List
7
7.8 H: Terminal Functions
YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup 197
Setting Value Function Description
52 Sequence Timer Cancel Sets the command to cancel the currently active Sequence Timer.
ON : Cancel Active Sequence Timer
61 Speed Search from Fmax Sets the function to start speed search using an external reference although b3-01 = 0 [Speed Search Selection at Start = Disabled].
Note:
The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 61 and 62 are set at the same time.
62
Speed Search from Fref Sets the function to use an external reference to start speed search although b3-01 = 0 [Speed Search Selection at Start = Disabled].
Note:
The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 61 and 62 are set at the same time.
63
Field Weakening Sets the function to send the Field Weakening Level and Field Weakening Frequency Limit commands set in d6-01 [Field
Weakening Level] and d6-02 [Field Weakening Frequency Limit] when the input terminal is activated.
68 High Slip Braking (HSB)
Activate
Sets the command to use high-slip braking to stop the motor.
6A Drive Enable Sets the function to show dnE [Drive Enabled] on the keypad and ignore Run commands when the terminal is OFF.
70 Drive Enable 2 Sets the function to show dnE [Drive Enabled] on the keypad and ignore Run commands when the terminal is OFF.
ON : Run command is accepted.
OFF : Run command is disabled. When the drive is running, it stops according to b1-03 setting.
82 PI Switch to Aux Sets YF-xx [PI Auxiliary Control] parameters as primary PI loop parameters and disables b5-xx [PID Control].
Note:
When this input is active, YF-xx [PI Auxiliary Control] parameters will always be the primary PI loop parameters. Parameter
YF-20 [PI Aux Main PI Speed Control] does not have an effect.
83
Dedicated Multi-Setpoint
YA-02
Sets the function to set the PID setpoint to YA-02 [Setpoint 2].
Note:
If you use this function and one of H1-xx = 3E or 3F [PID Setpoint Selection 1 or 2] at the same time, the drive will detect an
oPE03 [Multi-Function Input Setting Err].
ON : YA-02 is PID setpoint.
OFF : YA-01 [Setpoint 1], YA-03 [Setpoint 3], or YA-04 [Setpoint 4] is PID setpoint.
84 Dedicated Multi-Setpoint
YA-03
Sets the function to set the PID setpoint to YA-03 [Setpoint 3]. Set this function and H1-xx = 83 [Dedicated Multi-Setpoint YA-02] at
the same time.
Note:
If you use this function and one of H1-xx = 3E or 3F [PID Setpoint Selection 1 or 2] at the same time, the drive will detect an
oPE03 [Multi-Function Input Setting Err].
ON : YA-03 is PID setpoint.
OFF : YA-01 [Setpoint 1], YA-02 [Setpoint 2], or YA-04 [Setpoint 4] is PID setpoint.
85 Dedicated Multi-Setpoint
YA-04
Sets the function to set the PID setpoint to YA-04 [Setpoint 4]. Set this function, H1-xx = 83 [Dedicated Multi-Setpoint YA-02], and
H1-xx = 84 [Dedicated Multi-Setpoint YA-03] at the same time.
Note:
If you use this function and one of H1-xx = 3E or 3F [PID Setpoint Selection 1 or 2] at the same time, the drive will detect an
oPE03 [Multi-Function Input Setting Err].
ON : YA-04 is PID setpoint.
OFF : YA-01 [Setpoint 1], YA-02 [Setpoint 2], or YA-03 [Setpoint 3] is PID setpoint.
88 Thermostat Fault Sets the drive to show the VLTS [Thermostat Fault] when the input terminal is ON.
Note:
This function is active when the drive is running.
A8
PI2 Control Disable Sets the command to disable the PI2 Control function. Parameter S3-12 [PI2 Control Disable Mode Sel] sets the output
performance.
ON : Enabled
OFF : Disabled
AA PI2 Control Inverse
Operation
Sets the command to change the sign of the PI2 Control input.
AB PI2 Control Integral Reset Sets the command to reset the PI2 Control integral value.
Note:
This input has priority over H1-xx = AC [MFDI Function Selection = PI2 Control Integral Hold].
AC
PI2 Control Integral Hold Sets the command to lock the PI2 Control integral value.
AD Select PI2 Control PI
Parameters
Sets the command to use the S3-06 [PI2 Control Proportional Gain] and S3-07 [PI2 Control Integral Time] values instead of the
b5-02 [Proportional Gain (P)] and b5-03 [Integral Time (I)] values. Set S3-01 = 0 [PI2 Control Enable Selection = Disabled] to
enable this function.
Note:
This multi-function input does not have an effect on PI2 Control. Use this input for the primary PI controller (b5-xx).
B9
Disable Pre-charge Sets the command to disable the Pre-charge function.
ON : Pre-charge function is disabled
