b4: Timer Function
No.
(Addr.
Hex)
Name Description Values Page
b4-01
(1A3)
Timer Function On-Delay
Time
Sets the on-delay and off-delay times for a digital timer output
(H2-oo=12).
The output is triggered by a digital input programmed to
H1-oo=18).
Default: 0.0 s
Min.: 0.0
Max.: 3000.0
–
b4-02
(1A4)
Timer Function Off-Delay
Time
Default: 0.0 s
Min.: 0.0
Max.: 3000.0
–
u
b5: PID Control
No.
(Addr.
Hex)
Name Description Values Page
b5-01
(1A5)
PID Function Setting
0: Disabled
1: Enabled (PID output becomes output frequency reference, deviation D
controlled)
Default: 0
Range: 0, 1
–
b5-02
(1A6)
Proportional Gain Setting
(P)
Sets the proportional gain of the PID controller.
Default: 1.00
Min.: 0.00
Max.: 25.00
–
b5-03
(1A7)
Integral Time Setting (I)
Sets the integral time for the PID controller.
Default: 1.0 s
Min.: 0.0
Max.: 360.0
–
b5-04
(1A8)
Integral Limit Setting
Sets the maximum output possible from the integrator as a percentage of the
maximum output frequency.
Default: 100.0%
Min.: 0.0
Max.: 100.0
–
b5-05
(1A9)
Derivative Time (D)
Sets D control derivative time.
Default: 0.00 s
Min.: 0.00
Max.: 10.00
–
b5-06
(1AA)
PID Output Limit
Sets the maximum output possible from the entire PID controller as a
percentage of the maximum output frequency.
Default: 100.0%
Min.: 0.0
Max.: 100.0
–
b5-07
(1AB)
PID Offset Adjustment
Applies an offset to the PID controller output. Set as a percentage of the
maximum output frequency.
Default: 0.0%
Min.: -100.0
Max.: 100.0
–
b5-08
(1AC)
PID Primary Delay Time
Constant
Sets a low pass filter time constant on the output of the PID controller.
Default: 0.00 s
Min.: 0.00
Max.: 10.00
–
b5-09
(1AD)
PID Output Level Selection
0: Normal output (direct acting)
1: Reverse output (reverse acting)
Default: 0
Range: 0, 1
–
b5-10
(1AE)
PID Output Gain Setting
Sets the gain applied to the PID output.
Default: 1.00
Min.: 0.00
Max.: 25.00
–
b5-11
(1AF)
PID Output Reverse
Selection
0: Negative PID output triggers zero limit.
1: Rotation direction reverses with negative PID output.
Note: When using setting 1, make sure reverse operation is permitted
by b1-04.
Default: 0
Range: 0, 1
–
b5-12
(1B0)
PID Feedback Loss
Detection Selection
0: No fault. Digital output only.
1: Fault detection. Alarm output, drive continues operation.
2: Fault detection. Fault output, drive output is shut off.
3: No fault. Digital output only. No fault detection when PID control is
disabled.
4: Fault detection. Alarm is triggered and drive continues to run. Fault
detection even when PID is disabled.
5: Fault detection. Drive output shuts off. No fault detection when PID control
is disabled.
Default: 0
Range: 0 to 5
–
b5-13
(1B1)
PID Feedback Loss
Detection Level
Sets the PID feedback loss detection level as a percentage of the maximum
output frequency.
Default: 0%
Min.: 0
Max.: 100
–
B.2 b: Application
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
187
B
Parameter List

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
