No.
(Addr.
Hex)
Name Description Values Page
b5-94
(B94)
<1>
EZ Wake-up Level
When b5-95 is set to 0 (Absolute), the drive wakes-up when the PID Feedback
(H3-oo = 20) drops below this level for the time set in b5-96.
For reverse-acting, the PID Feedback must be above this level for the time set
in b5-96.
When b5-95 is set to 1 (Setpoint Delta), the drive wakes-up when the PID
Feedback (H3-oo = 20) drops below the PID Setpoint minus this level (for
normal acting PID) for the time set in b5-96.
For reverse-acting, Wake-up level is PID Setpoint plus this level. The PID
Feedback must be above the wake-up level for the time set in b5-96.
Default: 0.00%
Min.: 0.00
Max.: 600.00
b5-95
(B95)
<1>
EZ Wake-up Mode
Sets how the wake-up level is determined.
0: Absolute
1: Setpoint Delta
Default: 0
Range: 0, 1
b5-96
(B96)
<1>
EZ Wake-up Time
The drive will wake up when the PID Feedback drops below the b5-94, EZ
Wake-up Level for the time set in this parameter.
Default: 1.0 s
Min.: 0.0
Max.: 1000.0
<1> Unit and resolution are determined by b5-20, b5-39 and b5-46. Internally limited to b5-38. Changing b5-20, b5-38 and b5-39 will not automatically
update the value of this parameter.
<2> Parameter is only effective when EZ Sleep is enabled by setting b5-89 to 1.
<3> Unit, range and resolution is determined by b5-90. Changing b5-90 will not automatically update the value of this parameter.
u
b6: Dwell Function
No.
(Addr.
Hex)
Name Description Values Page
b6-01
(1B6)
Dwell Reference at Start
Parameters b6-01 and b6-02 set the frequency to hold and the time to maintain
that frequency at start.
Default: 0.0 Hz
Min.: 0.0
Max.: 400.0
b6-02
(1B7)
Dwell Time at Start
Default: 0.0 s
Min.: 0.0
Max.: 10.0
b6-03
(1B8)
Dwell Reference at Stop
Parameters b6-03 and b6-04 set the frequency to hold and the time to maintain
that frequency at stop.
Default: 0.0 Hz
Min.: 0.0
Max.: 400.0
b6-04
(1B9)
Dwell Time at Stop
Default: 0.0 s
Min.: 0.0
Max.: 10.0
u
b8: Energy Saving
No.
(Addr.
Hex)
Name Description Values Page
b8-01
(1CC)
Energy Saving Control
Selection
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
b8-04
(1CF)
Energy Saving Coefficient
Value
Determines the level of maximum motor efficiency. Setting range is 0.0 to
2000.0 for drives 3.7 kW and smaller. The display resolution depends on the
rated output power of the drive.
Default:
<1> <2>
Min.: 0.00
Max.: 655.00
b8-05
(1D0)
Power Detection Filter Time
Sets a time constant filter for output power detection. Default: 20 ms
Min.: 0
Max.: 2000
b8-06
(1D1)
Search Operation Voltage
Limit
Sets the limit for the voltage search operation as a percentage of the motor
rated voltage.
Default: 0%
Min.: 0
Max.: 100
<1> Default setting is dependent on parameter o2-04, Drive Model Selection.
<2> Parameter value changes automatically if E2-11 is manually changed or changed by Auto-Tuning.
B.2 b: Application
190
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
