YASKAWA P1000 User Manual

u
U3: Fault History
No.
(Addr.
Hex)
Name Description Analog Output Level Unit
U3-01 to
U3-04
(90 to 93
(800 to
803))
First to 4th Most Recent
Fault
Displays the first to the fourth most recent faults.
No signal output
available
–
U3-05 to
U3-10
(804 to
809)
5th to 10th Most Recent
Fault
Displays the fifth to the tenth most recent faults.
After ten faults, data for the oldest fault is deleted. The most recent fault
appears in U3-01, with the next most recent fault appearing in U3-02. The
data is moved to the next monitor parameter each time a fault occurs.
No signal output
available
–
U3-11 to
U3-14
(94 to 97
(80A to
80D))
Cumulative Operation
Time at 1st to 4th Most
Recent Fault
Displays the cumulative operation time when the first to the fourth most
recent faults occurred.
No signal output
available
1 h
U3-15 to
U3-20
(80E to
813)
Cumulative Operation
Time at 5th to 10th Most
Recent Fault
Displays the cumulative operation time when the fifth to the tenth most
recent faults occurred. No signal output
available
1 h
U3-21
(300B)
Date Year at Most Recent
Fault
Displays the year when the most recent fault occurred.
No signal output
available
–
U3-22
(300C)
Date Month and Day at
Most Recent Fault
Displays the date and day when the most recent faults occurred.
No signal output
available
–
U3-23
(300D)
Time Hours and Minutes
at Most Recent Fault
Displays the time when the most recent fault occurred.
No signal output
available
–
U3-24
(300E)
Date Year at 2nd Most
Recent Fault
Displays the year when the second most recent fault occurred.
No signal output
available
–
U3-25
(300F)
Date Month and Day at
2nd Most Recent Fault
Displays the date and day when the second most recent fault occurred.
No signal output
available
–
U3-26
(3010)
Time Hours and Minutes
at 2nd Most Recent Fault
Displays the time when the second most recent fault occurred.
No signal output
available
–
U3-27
(3011)
Date Year at 3rd Most
Recent Fault
Displays the year when the most third recent fault occurred.
No signal output
available
–
U3-28
(3012)
Date Month and Day at 3rd
Most Recent Fault
Displays the date and day when the third most recent fault occurred.
No signal output
available
–
U3-29
(3013)
Time Hours and Minutes
at 3rd Most Recent Fault
Displays the time when the third most recent fault occurred.
No signal output
available
–
U3-30
(3014)
Date Year at 4th Most
Recent Fault
Displays the year when the fourth most recent fault occurred.
No signal output
available
–
U3-31
(3015)
Date Month and Day at 4th
Most Recent Fault
Displays the date and day when the fourth most recent fault occurred.
No signal output
available
–
U3-32
(3016
Time Hours and Minutes
at 4th Most Recent Fault
Displays the time when the fourth most recent fault occurred.
No signal output
available
–
U3-33
(3017)
Date Year at 5th Most
Recent Fault
Displays the year when the fifth most recent fault occurred.
No signal output
available
–
U3-34
(3018)
Date Month and Day at 5th
Most Recent Fault
Displays the date and day when the fifth most recent fault occurred.
No signal output
available
–
U3-35
(3019)
Time Hours and Minutes
at 5th Most Recent Fault
Displays the time when the fifth most recent fault occurred.
No signal output
available
–
U3-36
(301A)
Date Year at 6th Most
Recent Fault
Displays the year when the sixth most recent fault occurred.
No signal output
available
–
U3-37
(301B)
Date Month and Day a 6th
Most Recent Fault
Displays the date and day when the sixth most recent fault occurred.
No signal output
available
–
U3-38
(301C)
Time Hours and Minutes
at 6th Most Recent Fault
Displays the time when the most sixth recent fault occurred.
No signal output
available
–
U3-39
(301D)
Date Year at 7th Most
Recent Fault
Displays the year when the most seventh recent fault occurred.
No signal output
available
–
U3-40
(301E)
Date Month and Day at 7th
Most Recent Fault
Displays the date and day when the seventh most recent fault occurred.
No signal output
available
–
B.12 U: Monitors
230
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
