Page #221 background image
B.10 S: Special Application
u
S1: Dynamic Noise Control Function
No.
(Addr.
Hex)
Name Description Values Page
S1-01
(3200)
Dynamic Audible Noise
Control Function Selection
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
S1-02
(3201)
Voltage Reduction Rate
Sets the rate at which the output voltage will be reduced as a percentage of the
V/f pattern when operating with no load.
Default: 50.0%
Min.: 50.0
Max.: 100.0
S1-03
(3202)
Voltage Restoration Level
Sets the level when the drive should start restoring the voltage as a percentage
of the drive rated torque.
Default: 20.0%
Min.: 0.0
Max.: 90.0
S1-04
(3203)
Voltage Restoration
Complete Level
Sets the level at which voltage restoration for the V/f pattern is complete as a
percentage of the drive rated torque. If the output torque rises above the value
of S1-04, then the voltage will be controlled in a manner specified by the V/f
pattern setting.
Default: 50.0%
Min.: S1-03 + 10.0
Max.: 100.0
S1-05
(3204)
Voltage Restoration
Sensitivity Time Constant
Sets the level of sensitivity of the output torque and LPF time constants for
the voltage reduction rate. The level of sensitivity can be adjusted in
accordance with the load response.
Default: 1.000 s
Min.: 0.000
Max.: 3.000
S1-06
(3205)
Voltage Restoration Time
Constant at Impact
Sets the voltage restoration time constant if an impact load is added. Default: 0.050 s
Min.: 0.000
Max.: 1.000
S1-07
(323C)
Output Phase Loss Level for
Dynamic Noise Control
Reduces the output phase loss level when Dynamic Noise Control is active. Default: 100.0%
Min.: 10.0
Max.: 100.0
u
S2: Programmable Run Timers
No.
(Addr.
Hex)
Name Description Values Page
S2-01
(3206)
Sequence Timer 1 Start
Time
Sets the start time for timer 1. The value must be set less than or equal to S2-02. Default: 00:00
Min.: 00:00
Max.: 24:00
<1>
S2-02
(3207)
Sequence Timer 1 Stop Time
Sets the stop time for timer 1. The value must be set greater than or equal to
S2-01.
Default: 00:00
Min.: 00:00
Max.: 24:00
<1>
S2-03
(3208)
Sequence Timer 1 Day
Selection
Sets the days for which sequence timer 1 is active.
0: Timer disabled
1: Daily
2: Mon - Fri
3: Sat - Sun
4: Monday
5: Tuesday
6: Wednesday
7: Thursday
8: Friday
9: Saturday
10: Sunday
10: Sunday
Default: 0
Range: 0 to 10
S2-04
(3209)
Sequence Timer 1 Selection
Sets the action that occurs when sequence timers 1 is active.
0: Digital output only
1: Run
2: Run - PI disable
Default: 0
Range: 0 to 2
S2-05
(320A)
Sequence Timer 1 Reference
Source
Selects the frequency reference source used for running the drive when
sequence timer 1 is active (only applicable when S2-04 is set to 1 or 2).
0: Operator (d1-01)
1: Operator (d1-02)
2: Operator (d1-03)
3: Operator (d1-04)
4: Terminals
5: Serial communication
6: Option card
7: Pulse input
Default: 0
Range: 0 to 7
B.10 S: Special Application
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
221
B
Parameter List
