B.2 b: Application
Application parameters configure the source of the Run command, DC Injection Braking, Speed Search, timer functions, PID
control, the Dwell function, Energy Savings, and a variety of other application-related settings.
u
b1: Operation Mode Selection
No.
(Addr.
Hex)
Name Description Values Page
b1-01
(180)
Frequency Reference
Selection 1
0: Digital operator
1: Analog input terminals
2: MEMOBUS/Modbus communications
3: Option PCB
4: Pulse input (terminal RP)
Default: 1
Range: 0 to 4
92
b1-02
(181)
Run Command
Selection 1
0: Digital operator
1: Digital input terminals
2: MEMOBUS/Modbus communications
3: Option PCB
Default: 1
Range: 0 to 3
93
b1-03
(182)
Stopping Method Selection
0: Ramp to stop
1: Coast to stop
2: DC Injection Braking to stop
3: Coast with timer
Default: 0
Range: 0 to 3
94
b1-04
(183)
Reverse Operation Selection
0: Reverse enabled.
1: Reverse disabled.
Default: 0
Range: 0, 1
–
b1-07
(186)
LOCAL/REMOTE Run
Selection
0: An external Run command must be cycled at the new source in order to be
activated.
1: An external Run command at the new source is accepted immediately.
Default: 0
Range: 0, 1
–
b1-08
(187)
Run Command Selection in
Programming Mode
0: Run command is not accepted while in Programming Mode.
1: Run command is accepted while in Programming Mode.
2: Prohibit entering Programming Mode during run.
Default: 0
Range: 0 to 2
–
b1-11
(1DF)
Run Delay Time Setting
After a Run command is entered, the drive output waits until this delay time
has passed before starting.
Default: 0 s
Min.: 0
Max.: 600
–
b1-14
(1C3)
Phase Order Selection
0: Standard
1: Switch phase order (reverses the direction of the motor)
Default: 0
Range: 0, 1
–
b1-15
(1C4)
Frequency Reference
Selection 2
Enabled when an input terminal set for “External reference” (H1-oo = 2)
closes.
0: Digital operator
1: Terminals (analog input terminals)
2: MEMOBUS/Modbus communications
3: Option card
4: Pulse train input
Default: 0
Range: 0 to 4
–
b1-16
(1C5)
Run Command
Selection 2
Enabled when a terminal set for “External reference” (H1-oo = 2) closes.
0: Digital operator
1: Digital input terminals
2: MEMOBUS/Modbus communications
3: Option card
Default: 0
Range: 0 to 3
–
b1-17
(1C6)
Run Command at Power Up
0: Disregarded. A new Run command must be issued after power up.
1: Allowed. Motor will start immediately after power up if a Run command
is already enabled.
Default: 0
Range: 0, 1
–
u
b2: DC Injection Braking and Short Circuit Braking
No.
(Addr.
Hex)
Name Description Values Page
b2-01
(189)
DC Injection Braking Start
Frequency
Sets the frequency at which DC Injection Braking starts when “Ramp to stop”
(b1-03 = 0) is selected.
Default: 0.5 Hz
Min.: 0.0
Max.: 10.0
96
b2-02
(18A)
DC Injection Braking
Current
Sets the DC Injection Braking current as a percentage of the drive rated current. Default: 50%
Min.: 0
Max.: 100
–
b2-03
(18B)
DC Injection Braking Time
at Start
Sets DC Injection Braking time at start. Disabled when set to 0.00 seconds. Default: 0.00 s
Min.: 0.00
Max.: 10.00
–
