YASKAWA P1000 User Manual

B.4 d: References
Reference parameters set the various frequency reference values during operation.
u
d1: Frequency Reference
No.
(Addr.
Hex)
Name Description Values Page
d1-01
(280)
Frequency Reference 1
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-02
(281)
Frequency Reference 2
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-03
(282)
Frequency Reference 3
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-04
(283)
Frequency Reference 4
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-05
(284)
Frequency Reference 5
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-06
(285)
Frequency Reference 6
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-07
(286)
Frequency Reference 7
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-08
(287)
Frequency Reference 8
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-09
(288)
Frequency Reference 9
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-10
(28B)
Frequency Reference 10
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-11
(28C)
Frequency Reference 11
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-12
(28D)
Frequency Reference 12
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-13
(28E)
Frequency Reference 13
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-14
(28F)
Frequency Reference 14
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-15
(290)
Frequency Reference 15
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
d1-16
(291)
Frequency Reference 16
Sets the frequency reference for the drive. Setting units are determined by
parameter o1-03.
Default: 0.00 Hz
Min.: 0.00
Max.: 400.00
<1>
100
B.4 d: References
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
193
B
Parameter List

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
