YASKAWA P1000 User Manual

A.3 Drive Watt Loss Data
Table A.10 Watt Loss 200 V Class Three-Phase Models
Drive Model
Normal Duty
Rated Amps (A)
<1>
Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
2A0004 3.5 18.4 47 66
2A0006 6.0 31 51 82
2A0008 8.0 43 52 95
2A0010 9.6 57 58 115
2A0012 12.0 77 64 141
2A0018 17.5 101 67 168
2A0021 21 138 83 222
2A0030 30 262 117 379
2A0040 40 293 145 437
2A0056 56 371 175 546
2A0069 69 491 205 696
2A0081 81 527 257 785
2A0110 110 719 286 1005
2A0138 138 842 312 1154
2A0169 169 1014 380 1394
2A0211 211 1218 473 1691
2A0250 250 1764 594 2358
2A0312 312 2020 665 2686
2A0360 360 2698 894 3591
2A0415 415 2672 954 3626
<1> Value assumes the carrier frequency is 2 kHz (C6-02 = 1, 7, 8, 9, or A).
Table A.11 Watt Loss 400 V Class Three-Phase Models
Drive Model
Normal Duty
Rated Amps (A)
<1>
Heatsink Loss (W) Interior Unit Loss (W) Total Loss (W)
4A0002 2.1 20 48 68
4A0004 4.1 32 49 81
4A0005 5.4 45 53 97
4A0007 6.9 62 59 121
4A0009 8.8 66 60 126
4A0011 11.1 89 73 162
4A0018 17.5 177 108 285
4A0023 23 216 138 354
4A0031 31 295 161 455
4A0038 38 340 182 521
4A0044 44 390 209 599
4A0058 58 471 215 686
4A0072 72 605 265 870
4A0088 88 684 308 993
4A0103 103 848 357 1205
4A0139 139 1215 534 1749
4A0165 165 1557 668 2224
4A0208 208 1800 607 2408
4A0250 250 2379 803 3182
4A0296 296 2448 905 3353
4A0362 362 3168 1130 4298
A.3 Drive Watt Loss Data
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
181
A
Specifications

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
