YASKAWA P1000 User Manual

No.
(Addr.
Hex)
Name Description Analog Output Level Unit
U1-12
(4B)
Drive Status
Verifies the drive operation status.
U1 - 12=
00000000
During run
During zero-speed
During REV
During fault reset
signal input
During speed agree
Drive ready
During alarm
detection
During fault detection
1
1
1
1
1
1
1
1
No signal output
available
–
U1-13
(4E)
Terminal A1 Input Level
Displays the signal level to analog input terminal A1.
10 V: 100% 0.1%
U1-14
(4F)
Terminal A2 Input Level
Displays the signal level to analog input terminal A2.
10 V: 100% 0.1%
U1-15
(50)
Terminal A3 Input Level
Displays the signal level to analog input terminal A3.
10 V: 100% 0.1%
U1-16
(53)
Output Frequency after
Soft Starter
Displays output frequency with ramp time and S-curves. Units determined
by o1-03.
10 V: Max frequency 0.01 Hz
U1-18
(61)
oPE Fault Parameter
Displays the parameter number that caused the oPE02 operation error. No signal output
available
–
U1-19
(66)
MEMOBUS/Modbus
Error Code
Displays the contents of a MEMOBUS/Modbus error.
U1 - 19=
00000000
CRC Error
Data Length Error
Not Used
Parity Error
Overrun Error
Framing Error
Timed Out
Not Used
1
1
0
1
1
1
1
0
No signal output
available
–
U1-24
(7D)
Input Pulse Monitor
Displays the frequency to pulse train input terminal RP.
Determined by H6-02 1 Hz
U1-25
(4D)
Software Number (Flash)
FLASH ID No signal output
available
–
U1-26
(5B)
Software No. (ROM)
ROM ID No signal output
available
–
U1-29
(7AA)
Software No. (PWM) PWM ID
No signal output
available
–
U1-75
(851)
Time-Hour/Minute Displays the current time (Hours and Minutes).
No signal output
available
–
U1-76
(852)
Date – Year Displays the current year.
No signal output
available
–
U1-77
(853)
Date – Month/Day Displays the current date (Month and Date).
No signal output
available
–
U1-78
(854)
Date – Week Day
Displays the current date of the week.
0: Sunday
1: Monday
2: Tuesday
3: Wednesday
4: Thursday
5: Friday
6: Saturday
No signal output
available
–
<1> The number of decimal places in the parameter value depends on the drive model and the ND selection. This value has two decimal places (0.01
A) if the drive is set for a maximum applicable motor capacity up to and including 11 kW, and one decimal place (0.1 A) if the maximum applicable
motor capacity is higher than 11 kW.
<2> When reading the value of this monitor via MEMOBUS/Modbus, a value of 8192 is equal to 100% of the drive rated output current.
B.12 U: Monitors
228
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
