YASKAWA P1000 User Manual

Drive Model
Fuse Type
Manufacturer: Bussmann
Model Fuse Ampere Rating (A)
2A0138 FWH-350A 350
2A0169 FWH-400A 400
2A0211 FWH-400A 400
2A0250 FWH-600A 600
2A0312 FWH-700A 700
2A0360 FWH-800A 800
2A0415 FWH-1000A 1000
Three-Phase 400 V Class
4A0002 FWH-40B 40
4A0004 FWH-50B 50
4A0005 FWH-70B 70
4A0007 FWH-70B 70
4A0009 FWH-90B 90
4A0011 FWH-90B 90
4A0018 FWH-80B 80
4A0023 FWH-100B 100
4A0031 FWH-125B 125
4A0038 FWH-200B 200
4A0044 FWH-250A 250
4A0058 FWH-250A 250
4A0072 FWH-250A 250
4A0088 FWH-250A 250
4A0103 FWH-250A 250
4A0139 FWH-350A 350
4A0165 FWH-400A 400
4A0208 FWH-500A 500
4A0250 FWH-600A 600
4A0296 FWH-700A 700
4A0362 FWH-800A 800
4A0414 FWH-800A 800
4A0515 FWH-1000A 1000
4A0675 FWH-1200A 1200
4A0930 FWH-1200A 1200
4A1200 FWH-1600A 1600
Three-Phase 600 V Class
5A0003
<1>
FWP-50B 50
5A0004
<1>
FWP-50B 50
5A0006
<1>
FWP-60B 60
5A0009
<1>
FWP-60B 60
5A0011
<1>
FWP-70B 70
5A0017
<1>
FWP-100B 100
5A0022
<1>
FWP-100B 100
5A0027
<1>
FWP-125A 125
5A0032
<1>
FWP-125A 125
5A0041
<1>
FWP-175A 175
5A0052
<1>
FWP-175A 175
C.1 European Standards
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
237
C
Standards Compliance

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
