YASKAWA P1000 User Manual

n
Three-Phase 400 V Class
Drive Model Max. Motor Capacity kW (HP) Rated Output Current A
4A0002 0.75 (0.75) 2.1
4A0004 1.5 (2) 4.1
4A0005 2.2 (3) 5.4
4A0007 3.0 (3) 6.9
4A0009 3.7 (5) 8.8
4A0011 5.5 (7.5) 11.1
4A0018 7.5 (10) 17.5
4A0023 11 (15) 23
4A0031 15 (20) 31
4A0038 18.5 (25) 38
4A0044 22 (30) 44
4A0058 30 (40) 58
4A0072 37 (50) 72
4A0088 45 (60) 88
4A0103 55 (75) 103
4A0139 75 (100) 139
4A0165 90 (125) 165
4A0208 110 (150) 208
4A0250 132 (200) 250
4A0296 160 (250) 296
4A0362 185 (300) 362
4A0414 220 (350) 414
4A0515 250 (400-450) 515
4A0675 355 (500-550) 675
4A0930 500 (750) 930
4A1200 630 (1000) 1200
n
Three-Phase 600 V Class
Drive Model
Max. Motor Capacity kW (HP) Rated Output Current A
5A0003 1.5 (2) 2.7
5A0004 2.2 (3) 3.9
5A0006 3.7 (5) 6.1
5A0009 5.5 (7.5) 9
5A0011 7.5 (10) 11
5A0017 11 (15) 17
5A0022 15 (20) 22
5A0027 18.5 (25) 27
5A0032 22 (30) 32
5A0041 30 (40) 41
5A0052 37 (50) 52
5A0062 45 (60) 62
5A0077 55 (75) 77
5A0099 75 (100) 99
5A0125 90 (125) 125
5A0145 110 (150) 145
5A0192 160 (200) 192
5A0242 185 (250) 242
1.1 Model Number and Nameplate Check
24
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
