YASKAWA P1000 User Manual

n
IP20/NEMA Type 1 Enclosure Drives
Note: Removing the top protective cover or bottom conduit bracket from an IP20/NEMA Type 1 enclosure drive voids NEMA Type 1 protection
while maintaining IP20 conformity.
W1
4-d
H1
H
H0
H2
H3
W
Max.W2
D
D1
t2
t1
Figure 2Figure 1
W1
H4
H
H0
H1
H3 H2
D
D1
t1
4-d
W
Max.W2
Table 2.2 Dimensions for IP20/NEMA Type 1 Enclosure: 200 V Class
Drive Model
Figure
Dimensions mm (in)
Wt. kg
(lb)
W H D W1 W2 H0 H1 H2 H3 H4 D1 t1 t2 d
2A0004F
1
<1>
140
(5.51)
300
(11.81)
147
(5.79)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
38
(1.50)
5
(0.20)
– M5
3.3
(7.3)
2A0006F
140
(5.51)
300
(11.81)
147
(5.79)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
38
(1.50)
5
(0.20)
– M5
3.3
(7.3)
2A0008F
140
(5.51)
300
(11.81)
147
(5.79)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
38
(1.50)
5
(0.20)
– M5
3.4
(7.5)
2A0010F
140
(5.51)
300
(11.81)
147
(5.79)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
38
(1.50)
5
(0.20)
– M5
3.4
(7.5)
2A0012F
140
(5.51)
300
(11.81)
147
(5.79)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
38
(1.50)
5
(0.20)
– M5
3.4
(7.5)
2A0018F
140
(5.51)
300
(11.81)
164
(6.46)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
55
(2.17)
5
(0.20)
– M5
3.8
(8.2)
2A0021F
140
(5.51)
300
(11.81)
164
(6.46)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
55
(2.17)
5
(0.20)
– M5
3.8
(8.2)
2A0030F
140
(5.51)
300
(11.81)
167
(6.57)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
55
(2.17)
5
(0.20)
– M5
4.2
(9.3)
2A0040F
140
(5.51)
300
(11.81)
167
(6.57)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
55
(2.17)
5
(0.20)
– M5
4.2
(9.3)
2A0056F
180
(7.09)
340
(13.39)
187
(7.36)
160
(6.30)
–
300
(11.81)
284
(11.18)
7.9
(0.31)
40
(1.57)
1.5
(0.06)
75
(2.95)
5
(0.20)
– M5
5.9
(13.0)
2A0069F
220
(8.66)
400
(15.75)
197
(7.76)
192
(7.56)
–
350
(13.78)
335
(13.19)
7.9
(0.31)
50
(1.97)
1.5
(0.06)
78
(3.07)
5
(0.20)
– M6
9
(20.1)
2A0081F
220
(8.66)
400
(15.75)
197
(7.76)
192
(7.56)
–
350
(13.78)
335
(13.19)
7.9
(0.31)
50
(1.97)
1.5
(0.06)
78
(3.07)
5
(0.20)
– M6
10
(22.0)
2A0110F
2
<1>
254
(10.00)
534
(21.02)
258
(10.16)
195
(7.68)
7.9
(0.31)
400
(15.75)
385
(15.16)
7.7
(0.30)
134
(5.28)
1.5
(0.06)
100
(3.94)
2.2
(0.09)
2.286
(0.09)
M6
23
(50.7)
2A0138F
279
(10.98)
614
(24.17)
258
(10.16)
220
(8.66)
7.9
(0.31)
450
(17.72)
435
(17.13)
7.7
(0.30)
164
(6.46)
–
100
(3.94)
2.2
(0.09)
2.286
(0.09)
M6
28
(61.7)
2A0169F
329
(12.95)
730
(28.74)
283
(11.14)
260
(10.24)
7.9
(0.31)
550
(21.65)
535
(21.06)
7.7
(0.30)
180
(7.09)
–
110
(4.33)
2.2
(0.09)
2.286
(0.09)
M6
41
(90.4)
2A0211F
329
(12.95)
730
(28.74)
283
(11.14)
260
(10.24)
7.9
(0.31)
550
(21.65)
535
(21.06)
7.7
(0.30)
180
(7.09)
–
110
(4.33)
2.2
(0.09)
2.286
(0.09)
M6
42
(92.6)
2.1 Mechanical Installation
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
31
2
Mechanical Installation

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
