8 Development Support Tool
8.3 Basic Settings
8-4
HW1484528
HW1484528
8.3 Basic Settings
8.3.1 Connecting a PC with the YRC1000micro
Connect PC with the YRC1000micro by using the Ethernet cable as
shown in chapter 7.2 “Connecting YRC1000micro with PC” .
8.3.2 Communication Settings
The MotoPlusIDE enables functions to be used individually for all
controllers connected with a PC. Register the communication settings of
the controller in advance, and then select upon use.
For MotoPlus Monitor, only one controller which is connected with the
programming pendant can use the functions. Therefore, registration of
the communication settings is not necessary.
Fig. 8-3: Communication Settings
8.3.3 Setting Procedure
1. Select the "Debug" menu in MotoPlusIDE, and then select
"Communication Settings”.
2. In the window, register the IP address and any name for the controller.
Fig. 8-4: Communication Settings Window
To Next Page
