8.7.2 Acquiring the Serial File (MotoPlus Monitor)
Acquires the serial file from the controller.
1. Select {Protection Key} in MotoPlus Monitor.
2. Select the Memory Device to save the serial file.
3. Press {Save}.
The serial file (MPSERIAL.DAT) is saved in the root folder of the selected
memory device.
Fig. 8-16: Serial File Acquisition Window
8.7.3 Generating the Protection Key (MotoPlusIDE)
Generate the protection key from the acquired serial file.
1. Open the project of the application by using MotoPlusIDE, and build once.
2. Select "Protection Key" from the "Debug" menu.
3. Press {Open}, and select the acquired serial file (MPSERIAL.DAT).
4. Press {Generate}.
The key file (application name.KEY) is generated in the same folder as the
OUT file of the application.
Fig. 8-17: Protection Key Generation Window
