Yealink SIP-T52S Administrator's Guide

Appendix
1069
3. User A places User B on hold.
User A Proxy Server User B
F1. INVITE B
F2. INVITE B
F7. ACK
F8. ACK
F3. 180 Ringing
F6. 200 OK
F5. 200 OK
F4. 180 Ringing
F12. 200 OK
F9. INVITE B (sendonly)
F10. INVITE B (sendonly)
F11. 200 OK
F14. ACK
F13. ACK
No RTP packets being sent
2-way RTP channel established
Step
Action
Description
F1
INVITE—User A to Proxy Server
User A sends an INVITE message to a
proxy server. The INVITE request is an
invitation to User B to participate in a call
session.
In the INVITE request:
 The IP address of User B is inserted
in the Request-URI field.
 User A is identified as the call
session initiator in the From field.
 A unique numeric identifier is
assigned to the call and is inserted in
the Call-ID field.
 The transaction number within a
single call leg is identified in the
