Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series/T5 Series/CP860/CP920 IP Phones
1070
CSeq field.
The media capability User A is ready
to receive is specified.
The port on which User B is prepared
to receive the RTP data is specified.
INVITE—Proxy Server to User B
The proxy server maps the SIP URI in the
To field to User B. The proxy server sends
the INVITE message to User B.
180 Ringing—User B to Proxy
Server
User B sends a SIP 180 Ringing response
to the proxy server. The 180 Ringing
response indicates that the user is being
alerted.
180 Ringing—Proxy Server to
User A
The proxy server forwards the 180 Ringing
response to User A. User A hears the ring-
back tone indicating that User B is being
alerted.
200 OK—User B to Proxy Server
User B sends a SIP 200 OK response to the
proxy server. The 200 OK response
notifies the proxy server that the
connection has been made.
200 OK—Proxy Server to User A
The proxy server forwards the 200 OK
message to User A. The 200 OK response
notifies User A that the connection has
been made.
ACK—User A to Proxy Server
User A sends a SIP ACK to the proxy
server. The ACK confirms that User A has
received the 200 OK response. The call
session is now active.
ACK—Proxy Server to User B
The proxy server sends the SIP ACK to
User B. The ACK confirms that the proxy
server has received the 200 OK response.
The call session is now active.
INVITE—User A to Proxy Server
User A sends a mid-call INVITE request to
the proxy server with new SDP session
parameters, which are used to place the
call on hold.
INVITE—Proxy Server to User B
The proxy server forwards the mid-call
INVITE message to User B.
To Next Page
