7-32
IM WT3001E-51EN
• Performing Cursor Measurements
2.
Press SHIFT+MEASURE (CURSOR) to display the Cursor menu.
• Turning ON/OFF Cursor Measurement
3.
Press the Bar Cursor soft key to select ON or OFF.
If ON is selected, the result of the cursor measurement is displayed.
• Moving the Cursors
4.
Press the Bar C1 +/Bar C2 x soft key to set the cursor target to Bar C1 +, Bar C2 x,
or both Bar C1 + and Bar C2 x.
• If you select Bar C1 +, the position of cursor + can be moved.
• If you select Bar C2 x, the position of cursor x can be moved.
• If you select both Bar C1 + and Bar C2 x, the two cursors can be moved without changing
the spacing between the two. The value of the digit being specified by Bar C1 + changes.
5.
Press the cursor keys to set and move the cursor position in terms of the
harmonic order.
7.9 Displaying the Bar Graph and Making Cursor Measurements
To Next Page
