viii EA3600 Network Connect Product Reference Guide
Chapter Descriptions
Topics covered in this guide are as follows:
•
Chapter 1, Initial Setup, provides information about how to perform setup and configure the EA3600 adapter.
•
Chapter 2, Ethernet Interface, provides an overview of the Industrial Ethernet (IE) interface.
•
Chapter 3, Barcode Transfer, provides the details of how this transfer is accomplished, independent of the
protocol being used.
•
Chapter 4, PROFINET Interface, provides information about PROFINET IO modules including the steps and
screen shots to configure the Siemens S7 communications, and transferring barcode data from the EA3600.
•
Chapter 5, EtherNet/IP Interface, provides information about I/O assemblies, I/O connections, steps to
configure Rockwell Automation ControlLogix communication, and transferring barcode data from the
EA3600.
•
Chapter 6, Modbus TCP Interface, provides information about using the Modbus TCP interface to transfer
barcode data from the EA3600.
•
Appendix A, Troubleshooting provides the symptoms and solutions to common issues.
Notational Conventions
The following conventions are used in this document:
•
Italics are used to highlight the following:
• Chapters and sections in this guide
• Related documents
•
Bold text is used to highlight the following:
• Dialog box, window and screen names
• Drop-down list and list box names
• Check box and radio button names
• Icons on a screen
• Key names on a keypad
• Button names on a screen.
•
Bullets (•) indicate:
• Action items
• Lists of alternatives
• Lists of required steps that are not necessarily sequential.
•
Sequential lists (e.g., those that describe step-by-step procedures) appear as numbered lists.
