1 - 2 EA3600 Network Connect Product Reference Guide
EA3600 Initial Settings and Status
Factory Default Settings
It is important to note the factory default configuration of the EA3600 described in this section. In the event that the
default configuration does not match your desired configuration, either the Zebra Industrial Ethernet Configuration
Utility or the appropriate PLC vendor software must be used to modify the configuration.
The factory default configuration of the EA3600 is dependent upon the SKU purchased and is set as follows.
•
For Rockwell Automation SKU, EtherNet/IP is the default Active Industrial Ethernet Protocol.
•
For Siemens SKU, PROFINET is the default Active Industrial Ethernet Protocol.
•
IP Address mode: DHCP (Dynamic Host Control Protocol) with a 30 second timeout.
Reset Button
A Reset button is available on the EA3600 in the event that you would like to restore the EA3600 to its factory
defaults. To perform a factory reset, use a paper clip to hold down the Reset button for 10+ seconds. The Device
Status LED turns off to indicate that the button was held for a long enough period of time. Upon release of the
Reset button the internally saved configuration is cleared and the EA3600 reboots.
Figure 1-1 EA3600 Reset Button
NOTE The EA3600 factory default Ethernet IP address configuration has DHCP enabled, and a 30 second
timeout on DHCP. In the event that the DHCP address is not received within the timeout value of 30
seconds, the device falls back to an AutoIP address of 192.168.0.100.
