5 - 2 EA3600 Network Connect Product Reference Guide
Supported Objects
The EtherNet/IP interface supports the following CIP objects:
•
Identity
•
Message Router
•
TCP/IP Interface
•
Ethernet Link
•
Connection Manager
•
Assembly.
TCP/IP Interface Object
The TCP/IP Interface object provides the ability to get and set TCP/IP configuration parameters. The IP address
configuration may be set through the TCP/IP Interface object, but requires a device reset before any changes take
effect.
Ethernet Link Object
The Ethernet Link object provides the ability to get link speed and duplex configuration parameters. The link
configuration may not be changed through this object; all attributes are read-only.
I/O Assemblies
The EtherNet/IP interface includes two Assembly object instances that hold parameters and data used in the
transfer of barcode data received from the scanner by the EA3600 to the controller.
Status and Barcode Data Assembly
Instance: 100/101
Access:Get
Size: 496 bytes
The Status and Barcode Data assembly holds the current status of the barcode transfer and the barcode data itself.
The format of the assembly data follows that described in the Status and Barcode Data Assembly section above.
The Input Data field size 484 bytes.
Barcode Transfer Control Assembly
Instance:150
Access: Get / Set
Size:6 bytes
The Barcode Transfer Control assembly is used for handshaking during barcode transfer by the controller. The
format of the assembly data follows that described in the Barcode Transfer Control Assembly section above.
NOTE The EtherNet/IP interface does not support EtherNet/IP Address Conflict Detection.
