3 - 6 EA3600 Network Connect Product Reference Guide
Barcode Type Table
The type of barcode is identified by the 16 bit barcode type SSI ID input data entry.
NOTE Not all Symbologies are supported by the EA3600. Imaging/video and signature capture are not
supported.
Table 3-2 Code Types by SSI ID
Parameter SSI Number
Code 39 0x01
Codabar 0x02
Code 128 0x03
Discrete 2 of 5 (DTF) 0x04
IATA 0x05
Interleaved 2 of 5 (ITF) 0x06
Code 93 0x07
UPC-A 0x08
UPC-E 0x09
EAN-8 0x0A
EAN-13 0x0B
Code 11 0x0C
MSI 0x0E
EAN-128 0x0F
UPC-E1 0x10
PDF-417 0x11
Code 39 Full ASCII Conversion 0x13
Trioptic Code 39 0x15
Bookland EAN 0x16
UCC Coupon Extended Code 0x17
ISBT-128 0x19
MicroPDF417 0x1A
Data Matrix 0x1B
QR Code 0x1C
US Postnet 0x1E
