4 - 2 EA3600 Network Connect Product Reference Guide
PROFINET IO Modules
The I/O interface includes a single I/O module that contains parameters and data used in the transfer of barcode
data to the controller.
Status and Barcode Data IO Module
Module ID: 48
Submodule ID: 1
Access: Input / Output
Input Size: 80 bytes
Input Barcode Data Size: 64 bytes
The Status and Barcode Data IO module holds the current status of the barcode transfer and the barcode data
itself as well as the transfer control information used by the Controller. The format of the module data follows that
described in the Status and Barcode Data IO Module section above.
The Input Data field size 64 bytes.
Configuring Siemens S7 Communications
Register the GSDML File
Before the communications to the EA3600 can be configured, the GSDML file must be registered with TIA Portal.
This only has to be done once.
The steps to register the GSDML file using TIA Portal:
1. In the Project view menu, select: Options > Install General Station Description File (GSD).
2. Browse to the location of, and select the EA3600 GSDML file.
3. Click Install.
Adding the EA3600 to the I/O Configuration
In order for the controller to communicate with the EA3600, it must be added to the I/O configuration in the
controller program.
To add the EA3600 to the controller's I/O configuration using TIA Portal:
1. Open the Network view tab to show the PLC and the PROFINET network.
NOTE These steps assume a PLC and a PROFINET network were configured in the project.
