Ethernet Interface 2 - 3
Sample Application Files
To aid in initial application development, sample applications are provided. These sample applications include the
use of the Scanner Function Blocks and/or Scanner Routines that are also provided as separate exported
components. Three sample applications are provided and are located in the folders that match their respective
protocols and development environment.
•
EthernetIP\Logix_v24\EA3600Sample.zip
This sample must be unzipped before it is loaded. The sample application was built using RS Logix Designer
Studio 5000 v24. It uses ScannerRoutine which abstracts much of the EA3600 logic necessary to work with
scanning.
•
Profinet\TIAv15.1\EA3600_TIA_Sample_v15.1.zap15_1
This archived sample application was built using Totally Integrated Automation (TIA) v15.1 SP2. To load this
sample application, use the Retrieve feature from TIA v15.1 or higher File menu. It uses the EA3600 Library
which abstracts much of the EA3600 logic necessary to work with scanning.
Sample Function Block/Library/Routine Files
In a further effort to aid application developers who use alternate versions of Rockwell Automation and Siemens
development environments, an exported Function Block, Library, and Routine are provided. These components are
listed below along with notes on how to load them into projects.
•
EthernetIP\Logix_v24\ScannerRoutine.L5X
From within RS Logix Designer Studio 5000, select Import Component\Routine from the File menu to load
this routine.
•
Profinet\TIAv15.1\EA3600Lib.zal15_1
From within TIA v15.1, open this Global library and drag and drop its components into your current project.
NOTE These files must be installed into the appropriate development environment for the sample applications to
work correctly.
