Ethernet Interface 2 - 7
3 Reserved Set to 0.
4 Clear Faults Set to clear any active interface faults. This bit is only effective on the rising edge
and when held for at least one requested packet interval (varies from 8ms to
100ms depending on protocol and PLC).
5 Start Scan Set to start a barcode scan.
On rising edge and when held for at least one requested packet interval (varies
from 8ms to 100ms depending on protocol and PLC) this bit causes a barcode
scan to be started at the scanner.
Note
: Scanning is automatically turned off when a barcode is read and must be
restarted to read the next code.
This bit only works with point-to-point EA3600 SKUs.
6 Stop Scan Set to stop an active barcode scan.
On rising edge and when held for at least one requested packet interval (varies
from 8ms to 100ms depending on protocol and PLC) this bit causes the scanner
to stop scanning.
This bit only works with point-to-point EA3600 SKUs.
7 Send UI Action Set to trigger the scanner user action specified by the UIF code in the UI Action
Code output field.
The UIF code is sent to the scanner after the 0 to 1 transition of this bit. This bit
should stay 1 for at least one requested packet interval (varies from 8ms to
100ms depending on protocol and PLC).
This bit only works with point-to-point EA3600 SKUs.
8-15 Reserved Set to 0.
Table 2-5 Control Register Bit Assignments (Continued)
Bit Name Description
