Settings
136
text, information messages are in blue text, debug messages are in green text, and error messages are in
red.
• Kernel Log - View all the Kernel Logs.
• Snapshot - View all the Snapshot.
Backup
RxLogger Utility allows the user to make a zip file of the RxLogger folder in the device, which by default contains all
the RxLogger logs stored in the device.
Figure 104 Backup Message
Touch Yes to save the backup data.
Archiving
The user can view all the RxLogger logs stored in the RxLogger directory by default. These is not for live-viewing
logs.
Figure 105 Archive
Touch any of the options to view the log files.
Overlay View
To initiate Overlay view:
1. Open RxLogger.
2. Touch > Toggle Chat Head. The Main Chat Head icon appears on the screen.
The user can drag the Main Chat head icon around the screen. Touch the icon to open the Overlay View.
