Settings
138
Figure 107 Log File
Removing a Sub Chat Head Icon
To remove a sub chat Head icon, press and hold the icon until it disappears.
Backup
RxLogger Utility allows the user to make a zip file of the RxLogger folder in the device, which by default contains all
the RxLogger logs stored in the device.
Backup Now icon is always available in the Overlay View.
1. Touch the Backup Now icon. The Backup dialog box appears.
2. Touch Yes to create the back up.
About Phone
Use About phone settings to view information about the TC25. swipe down from the status bar and then touch
> About phone.
• Status - Touch to display the following:
• Battery status - Indicates if the battery is charging (on AC power) or discharging (on battery power).
• Battery level - Indicates the battery charge level.
• IP address - Displays the IP address of the device.
• Wi-Fi MAC address - Displays the Wi-Fi radio MAC address.
• Ethernet MAC address - Displays the Ethernet driver MAC address.
• Bluetooth address - Displays the Bluetooth radio Bluetooth address.
• Serial number - Displays the serial number of the device.
• Up time - Displays the time that the TC25 has been running since being turned on.
• SW components - Lists filenames and versions for various software on the TC25.
• Hardware components - Lists hardware components and associated part number.
• Battery Management - Displays information about the battery.
