Accessories
38
1-Slot Base Char
ge Only Cradle
The 1-Slot Base Charge On
ly Cra
dle provide
5 VDC for ch
arging:
•
TC25
•
Extended Power Pack
•
TC25 and Extended Power Pack
•
TC25 with Trig
ger Handle.
Setup
Figure 21
1-Slot Base Charge
Only Cradle Setup
Cable Routing
To cradle provides th
ree w
ays to route the USB cable:
•
Rear
•
Left side
•
Right side.
Power Supply
USB-C Cable
USB C Port
30
32
