Wireless
107
Figure 98 Set Up Wi-Fi Hotspot Dialog Box
5. In the Network name text field, edit the name for the hotspot.
6. Touch the Channel option and select a channel number from the drop-down list.
7. Touch the Security option and select a security method from the drop-down list.
None
WPA2 PSK.
8. In the Password text field, enter a password.
9. Touch Save.
Cellular Network Settings
Disabling Data When Roaming
To prevent the device from transmitting data over other carriers’ mobile networks when leaving an area that is
covered by the carrier’s networks. This is useful for controlling expenses if the service plan does not include data
roaming.
1. Swipe down from the status bar and then touch .
2. Touch More ....
3. Touch Cellular networks.
4. Slide the Data roaming switch to the on position. The Allow data roaming? dialog box appears.
5. Touch OK.
Enhanced 4G LTE Mode
Use LTE services to improve voice and other communication. (default - enabled).
NOTE If None is selected in the Security option, a password is not required.
NOTE Indonesian configurations do not support LTE.
