Getting Started
23
Figure 15
Remove microSD Card
8.
Lift the microSD card.
9.
Align the replacement micro
SD
card with the SD card slot.
Figure 16
Align microSD Card
10.
Push the micr
oSD card into the
SD card slot.
Figure 17
Push microSD Card in
to the SD Card Slot
11.
Replace the access Door.
12.
Secure the access door using the two screws.
