Accessories
40
Installing the Four Slot Battery Charger
Install the Four Slot Battery charger onto a 5-Slot Charge Only Cradle base. This provides a total for four
device charging slots and four battery charging slots.
NOTE: The Battery Charger must be installed in the first slot only.
1. Remove power from the cradle.
2. Using a Phillips screwdriver, remove the screw securing the cup to the cradle base.
3. Slide the cup to the front of the cradle.
