Zebra TC72 - Connecting a Headset to the 3.5 mm Audio Adapter

Accessories
61
Connecting a Headset to the 3.5 mm Audio Adapter
1. Connect the Quick Disconnect connect of the headset to the Quick Disconnect connector of the 3.5 mm
Quick Disconnect Adapter Cable.
2. Connect the audio jack of the 3.5 mm Quick Disconnect Adapter Cable to the 3.5 mm Audio Adapter.
Figure 41 Connect Adapter Cable to Audio Adapter
