List of lamps

PCLPN069

1 headlights HB

12 V 60 W P 20d

2 work lights H

12 V 65 W PGJ1

-5

3 front combination lights

turn si

nal li

hts P21W 12 V 21 W BA 15s

osition li

hts R5W 12 V 5 W BA 15s

4 low beam li

hts H

12 V 55 W PX26d

5 rear combined li

hts

tail lights and brake lights 12 V 5 /21W BAY 15d

turn signal lights 12 V 21 W BA 15s

6 cab illumination W5W 12 V 5 W W2.1x9.5d glass socket bul

7 switches in the ca

12 V 1.2 W W2x4.6d glass socket bul

ELECTRIC INSTALLATION

170
