Replacement of the transmission oil cleaner element with hydraulic pump suction filte
After replacement of the oil filter element of pushing filter of the brake system, after starting
the tractor the engine must be left running for at least one minute when self-bleeding of the brake
system occurs. During this time do not press the brake pedals in order to avoid bleeding of the brake
system.
Gearbox distributor - replacement of oil cleaner cartridge
G749
The gearbox distributor is located on the right side of the tractor behind the fuel tank; the oil cleaner is
accessible from the bottom of the tractor.
Before replacement of the oil cleaner cartridge, put a suitable container under the tractor to
catch any leaking oil.
1. Screw out the cleaner body (1).
2. Replace the filtration cartridge (2).
3. Reinstall the cleaner body (1).
The oil cleaner is placed on the left side of the gearbox.
Before replacing the oil cleaner element, place
a suitable vessel for dripping oil under the tractor.
1. Unscrew the body of the cleaner (1)
2. Replace the filtration element
3. Reassemble the body of the cleaner
P18N011
The oil cleaner is placed on the left side of the gearbox.
Before replacing the oil cleaner element, place
a suitable vessel for dripping oil under the tractor.
1. Unscrew the body of the cleaner (1)
2. Replace the filtration element
3. Reassemble the body of the cleaner
P18N012
