Zetor Proxima GP Series User Manual

Technical data of engines
Tractor type GP 80 GP 90 GP 100 GP 110
Engine model 1106 1206 1006 1306
Engine type
diesel, for-stroke with direct fuel injection,
turbocharged
Engine design serial, standing, water cooled
Number of cylinders 4
Cylinder capacity
cm
3
4156
Bore x stroke mm 105x120
Rated speed rpm 2200
Injection order 1-3-4-2
Engine pressure ratio 17.8
Max. limiter
revolutions
rpm 2460
Idle revolutions rpm 800 ± 25
Net power nominal
engine revolutions
measured according
to ISO 14396
kW 55.6 64.4 70.4 78,4
Specific fuel
consumption at
specified power
g/kWh 216 258 240 238
Specific fuel
consumption at max.
torque
g/kWh 216 214 213 212
Max. torque (Mt) 1480
rpm ISO14396
Nm 315.8 369.7 428.7 461,3
Reinforcement Mt
ECE R24
% 37.4 38.2 46.2 40,3
Engine lubrication pressure with gear pump
Maximum oil
consumption after 100
EH of engine running-
in
g/kWh 0.5
Oil pressure at
nominal engine
revolutions and oil
temperature of 80°C
MPa 0.2 - 0.5 0.2 - 0.5 0.2 - 0.5 0.2 - 0.5
Minimum oil pressure
at revolutions 750 rpm
and oil temperature of
80°C
MPa 0.08
Max. temperature of
cooling liquid
°C 110
Type of distribution OHV
Angle of injection
advance
° 11+/- 1.5 11+/- 1.5 11+/- 1.5 11+/- 1.5
Clearance of valves in
cold engine
- suction
- exhaust
mm
mm
0.3
0.4
MAIN TECHNICAL PARAMETERS
206
