3.1.6 Standard Electric Cables
(Refer to the MMC-288 References and Parts Source)
The following lists the various equivalent electric cables for the basic connections to the Standard
Processor:
3.1.6.1 Control Head Electric Cable
If the Control Head is hard-wired (no plugs) the electric cable must meet the following specifications
or may be ordered from ZF Marine Propulsion Systems Miramar, LLC:
• Seven-conductor with shield, twisted.
• Color Code – black, brown, red, orange, green, blue, and violet.
• 18 AWG (nearest metric equivalent - #1).
• 300V, 105 degrees C, UL VW1, stranded tinned copper wire.
• Maximum outside diameter: 0.390 inch (9,9mm)
3.1.6.2 Power, Start Interlock, Clutch Pressure, Alarm Electric Cable
3.1.6.2.1 Power Electric Cable Requirements
If Power
is hard-wired, (no plugs) the electric cable must meet the following specifications
or may be ordered from ZF Marine Propulsion Systems Miramar, LLC:
• Two-conductor, black and red with violet stripe, twisted.
• 14 AWG (#2,5 metric) or 12 AWG (#4 metric) may be used to crimp directly to the
Processor terminals. Refer to S-214 Automatic Power Selector Model: 13505 for cable
length and additional wire size requirements.
• 300V, 105 degrees C, UL VW1, stranded tinned copper wire.
• Maximum outside diameter: 0.390 inch (9,9mm).
3.1.6.2.2 Start Interlock Electric Cable Requirements
If Start Interlock
is hard-wired (no plugs) the electric cable must meet the following
specifications or may be ordered from ZF Marine Propulsion Systems Miramar, LLC:
• Two-conductor, both yellow with red stripe, twisted.
• 16 AWG (#1,5 metric).
• 300V, 105 degrees C, UL VW1, stranded tinned copper wire.
• Maximum outside diameter: 0.390 inch (9,9mm).
3.1.6.2.3 Clutch Pressure Interlock Electric Cable Requirements
When the Clutch Pressure Interlock
option is utilized, a pressure switch with a normally
open contact must be installed on the transmission, along with a Shuttle Valve
If the Clutch Pressure Switch is hard-wired (no plugs) the electric cable must
meet the
following specifications or may be ordered from ZF Marine Propulsion Systems Miramar,
LLC:
• Two-conductor, both light blue.
• 16 AWG (#1,5 metric).
• 300V, 105 degrees C, UL VW1, stranded tinned copper wire.
• Maximum outside diameter: 0.390 inch (9,9mm).
3.1.6.2.4 External Alarm Circuit Electric Cable Requirements
If the External Alarm Circuit
is hard-wired (no plugs) the electric cable must meet the
following specifications or may be ordered from ZF Marine Propulsion Systems Miramar,
LLC:
• Two-conductor, red and black, twisted.
• 16 AWG (#1,5 metric).
• 300V, 105 degrees C, UL VW1, stranded tinned copper wire.
• Maximum outside diameter: 0.390 inch (9,9mm).
