3.1.6.3 Serial Communication Electric Cable Requirements
The Serial Communication Harness is only required in Twin Screw applications or when an external
trolling actuator (9001) is utilized. The electric cable connects the Port Processor to the Starboard
Processor.
• Required only when hard-wiring the Processor.
• Refer to MMC-288 References and Parts Source.
3.1.6.4 Tach Sensor Electric Cable Requirements
The cable selected depends on what type of Sensor is being used:
3.1.6.4.1 AC Tach Input
• Two-conductor, twisted, shielded.
• 20 AWG (#0,5 metric)
• 300 V, 165 C, UL VW1, stranded tinned copper
• Maximum outside diameter: 0.390 inches (9,9mm)
3.1.6.4.2 Open Collector (Active)
• Three-conductor, twisted, shielded
• 20 AWG (#0,5 metric)
• 300 V, 165 C, UL VW1, stranded tinned copper
• Maximum outside diameter: 0.390 inches (9,9mm)
3.1.7 Additional Electric Cables
(Refer to the Parts List in MMC-288 References and Parts Source)
Depending on the requirements of the installer, the installation may use Harnesses, Electric Cables or
a combination of both. The various 9000 Series Processors may use all or a combination of the below
listed harnesses or cables. Refer to Table PREFACE-1 Processor List located after the cover sheet of
this manual to determine which harnesses are required.
The following lists the various equivalent electric cables:
3.1.8 Throttle Electric Cable Requirements
If Throttle is hard-wired, (no plugs) to the Processor, the electric cable must
meet the following
specifications or may be ordered from ZF Marine Propulsion Systems Miramar, LLC:
• Two-conductor, red and black, twisted, shielded.
• 16 AWG (#1,5 metric).
• 300V, 105 degrees C, UL VW1, stranded tinned copper wire.
• Maximum outside diameter: 0.390 inch (9,9mm).
3.1.9 Clutch Electric Cable Requirements
If Clutch Solenoids are hard-wired, (no plugs) to the Processor, the electric cable must
meet the
following specifications or may be ordered from ZF Marine Propulsion Systems Miramar, LLC:
• Two-conductor, red and black, twisted.
• 16 AWG (#1,5 metric).
• 300V, 105 degrees C, UL VW1, stranded tinned copper wire.
• Maximum outside diameter: 0.390 inch (9,9mm).
3.1.10 Clutch/Troll Electric Cable
3.1.10.1 Clutch Solenoid Electric Cable Requirements
If Clutch Solenoids
are hard-wired, (no plugs) to the Processor, the electric cable must meet the
following specifications or may be ordered from ZF Marine Propulsion Systems Miramar, LLC:
• Two-conductor, red and black, twisted.
• 16 AWG (#1,5 metric).
• 300V, 105 degrees C, UL VW1, stranded tinned copper wire.
• Maximum outside diameter: 0.390 inch (9,9mm).
