ZF MM9000 User Manual

57
EN 3340.758.003a - 2014-11
INSTALLATION
MM9000 Rev C.8 01/13 Page 57
MM9000 ClearCommand User Manual
Installation
4.3.6.2 Clutch Harness
A Plug the grey, 12 pin plug into the Clutch pigtail connector at the Processor.
B Run the cables to the Ahead and Astern solenoids at the transmission.
C Plug the DIN connector into the Ahead and Astern Solenoids.
D If Twin Screw, repeat steps A) thru C) on the opposite side.
4.3.6.3 Clutch/Troll Harness
A Plug the grey, 12 pin plug into the Clutch pigtail connector at the Processor.
B Run the cables to the transmission.
C Plug the DIN connector into the Ahead and Astern Solenoids.
D Plug the DIN connector into the Troll proportional solenoid, and if installed the Troll ON/OFF
solenoid.
E If Twin Screw, repeat steps A) thru D) on the opposite side.
NOTE: Ensure Port Processor connects to the Port Solenoid and the Starboard Processor connects to the
Starboard Processor.
NOTE: Ensure Port Processor connects to the Port Solenoid and the Starboard Processor connects to the
Starboard Processor.
