Zmorph VX User Manual

CNC milling workow
107
13. CNC milling
13.1 CNC PRO Milling Toolhead
CNC PRO is a toolhead used in milling and engraving operations. It consists of 300W
spindle, in a steel casing, and aluminum mounting that allows for attachment of the
toolhead to X-carriage of ZMorph VX machine.
By default provided with ER11 ⅛" collet, after exchanging collet chuck, can be expanded
to use up to 7 mm diameter shank cutters.
Main elements of CNC Pro toolhead:
Spindle in steel casing
Aluminium mounting base
ER11 collet mounting chuck
Toolhead cables
Specication:
Construction: Stainless steel housing
Hot End: ER-11 1/8" COLLET
Spindle motor: DC motor
Power: 300 W
Default work speed: 5 mm/s
Max work speed: 120 mm/s
Work area: up to 235 x 250 x 85 mm
Recommended cutting depth: 0.5 mm for
soft wood and polymers
Max cutting depth: 15 mm for ø 3 mm bit
Dimensions: 90 x 55 x 175 mm
